Motherboard | |
---|---|
Form factor | Mini ITX, mATX, μATX, ATX, eATX, SSI CEB |
max. Motherboard size | 305mm x 270mm (12" x 10.6") |
Installation Dimensions |
|
Height CPU cooler (max.) | 32mm |
Length graphics card (max.) | 270mm |
Drive Bays |
|
5.25" external | 2x¹ |
5.25" external (slim) | |
3.5" external | |
3.5" internal | 2x¹ |
2.5" internal | 8x¹ |
Front connectors |
|
USB 3.0 | 2x |
USB 2.0 | |
Power supply |
|
1U Server PSU | |
FlexATX PSU | |
Fan mounting option |
|
Inside | 2x 40mm (serial, 3pin (4pin connector)) |
Controls & LED |
|
Controls | Power-Switch Reset-Button |
LED | Power HDD Activity 3x Network Activity Alert |
other Data |
|
Dimensions (h/w/d) | 44.5 x 482 x 508mm |
Material | 1.0-1.2mm Steel |
Warranty | 24 months |
Scope of delivery & Features |
|
Scope of delivery |
Case Retail packaging Screw Set Mounting bracket for FlexATX PSU |
Features |
2x 40mm fan included USB 3.0 as block connector Universal ATX I/O plate 1x Riser slot |
Logistical data |
|
Weight | net = 5.60kgs gross = 7.44kgs |
